| Construction | Materials | Remark |
| Cover Glass | Chemical strengthened glass | Thickness: 1.1mm±0.05mm |
| Optical clear adhesive | OCR | Thickness: 0.175mm±0.05mm |
| ITO Glass | ITO Glass | Double side ITO glass; Thickness:0.4mm±0.05mm |
| item | Description | Unit |
| Touch Module Size | 6.8 | inch |
| Outer Dimension | 190.66*75.01 | mm |
| View Area | 161.59*61.22 | mm |
| Sensor Area | 169.55*74.41 | mm |
| Cover Thickness | 1.1 | |
| Number of Touch | 5 | |
| Interface | I2C | |
| Controller | Microchip |
