| Structure | Materials | Remark |
| Cover Glass | Chemical strengthened glass | Thickness: 3.0mm±0.05mm |
| Optical clear adhesive | OCR | Thickness: 0.175mm±0.05mm |
| ITO Glass | ITO Glass | Double side ITO glass; Thickness: 0.7mm±0.05mm |
| Item | Description | Unit |
| Touch Module Size | 12.1 | inch |
| Outer Dimension | 310.00*260.00 | mm |
| View Area | 246.76*185.32 | mm |
| Sensor Area | 259.50*203.00 | mm |
| Cover Thickness | 3.0 | mm |
| Number of Touch | 5 | |
| Input Type | USB | |
| Control Type | Microchip |
